Product Specification
1.Elegant & stylish design – Suitable for high-end venues such as conference centers, auditoriums, screening rooms, and multifunctional halls.
2.Super-comfortable molded sponge – PU molded sponge (45–65 kg/m³) with ergonomic contour; medium-height backrest with continuous raised back and integrated lumbar support shape, effectively relieving fatigue during prolonged sitting.
3.Practical writing board – ABS panel with aluminium alloy bracket.
4.Versatile armrest options – ABS armrest surface with optional integration for simultaneous interpretation devices or audio equipment.
5.Durable construction – PP + fiber painted outer panels for seat and back; torsion spring return mechanism for automatic seat cushion return.
6.Sturdy fixing – Aluminium alloy fixed feet.
Detailed Specifications
Foam – PU molded sponge, density 45–65 kg/m³, cold-cured polyurethane.
Fixed feet – Aluminium alloy, floor-fixing type.
Armrest – ABS armrest surface; optional built-in simultaneous interpretation or audio equipment.
Outer panels (seat & back) – Molded PP + fiber, painted finish.
Writing board – ABS panel with aluminium alloy bracket.
Return mechanism – Torsion spring mechanism for automatic seat cushion return when not in use.
Ergonomic design – Medium-height backrest with continuous raised back and integrated lumbar support shape made of sponge.
This auditorium seat model WL1203C-4 features a centre distance of 550 mm, seat depth of 780/815 mm, seat width of 650 mm, total height of 885/870 mm, seat height of 450 mm, armrest height of 630 mm, and backrest height of 620 mm. Additional dimension 515/545 mm is shown in the drawing. The writing board length is 430 mm (refer to drawing for full size). The seat cushion is made of PU molded sponge with density 45–65 kg/m³. The torsion spring return mechanism ensures automatic seat return. The writing board is constructed with an ABS panel and an aluminium alloy bracket. Armrests are made of ABS with an option to integrate simultaneous interpretation devices or audio equipment. Fixed feet are made of aluminium alloy. Outer panels are PP + fiber with painted finish. Ideal for conference centers, auditoriums, screening rooms, and multifunctional venues.
